ALP Lifting Eye - Standard Designed as an attachment link for lifting and transport of precast concrete units in combination with the ALP Lifting Pin Anchor System. The Lifting Eye consists of a Lifting Head with a protruding lever arm and a high strength Bail. The Lifting Head has a "T" slot that engages the head of a Lifting Pin Anchor. The rotation capabilities allow the lifting eye to stay oriented in the direction of loading without binding up. See pages 14 and 15 for Lifting Eye usage information. See ALP Supply website for Inspection and Maintenance Guidelines for routine inspection of lifting hardware.

Part # K - Load Range (Tons) L W T A B C D E F G H Ultimate Capacity in Tension (lbs) Weight (lbs) LPLE1T 1T-1.3T 7-11/32" 3" 1/2" 1-3/4" 7/8" 2-3/4" 15/32" 1-5/16" 2-1/8" 2-1/8" 1-1/16" 13,000 2.00 LPLE2T 1.5T-2.5T 9" 3-1/2" 5/8" 2-1/8" 1" 3-3/8" 11/16" 1-5/8" 2-9/16" 2-1/2" 1-1/2" 25,000 3.34 LPLE4T 3T-5T 11" 4-11/16" 11/16" 2-5/8" 1-15/32" 3-7/16" 29/32" 2-1/4" 3-3/8" 3-1/2" 2-1/16" 50,000 7.57 LPLE8T 6T-10T 15-1/2" 6-1/4" 1-1/16" 3-1/8" 2" 4-3/8" 1-1/4" 2-15/16" 4-1/2" 4-1/2" 2-5/8" 100,000 22.15 LPLE20T 12T-20T 20" 7-11/16" 1-3/8" 4-3/8" 2-13/16" 5-15/16" 1-11/16" 4-3/8" 5-5/8" 5-3/4" 3-7/16" 200,000 44.76 Rated Load Range (K) has a 5:1 safety factor.

A D E B K C L W F G H T Bail Serial # Lot # Loop Lifting Head Lever Arm/Tounge

02/2022 800.332.7090 sales@alpsupply.com alpsupply.com 22

LIFTING PIN SYSTEM
