ALP Lifting Pin Plus Urethane Recess Member ALP Lifting Pin Plus Magnetic Holding Plate (2-Piece) ALP Lifting Pin Plus Stud Plate and Wingnut - 3/8" Coil
The ALP Stud Plate is used to mount the Plus Recess Members to the form. Standard finish is plated. Installation Instructions: 1. Install the stud plate into the recess member. 2. Insert the lift pin into the recess member. 3. Insert the stud plate through a hole in the form. 4. The 3/8" wing nut is then used to tighten the recess member to the outside of the form.
ALP Holding Rod and Tapped Plate - 3/8" Coil
Part # Size Color D - Diameter H - Height Weight (lbs) LPPRM2T 2T Yellow 3-1/4" 1-7/16" 0.25 LPPRM4T 4T Orange 4" 1-7/8" 0.44 LPPRM8T 8T Green 5" 2-1/8" 1.01 Part # Size Fits Recess Member LPPMHP2T 2T LPPRM2T LPPMHP4T 4T LPPRM4T LPPMHP8T 8T LPPRM8T Part # Fits Size Weight (lbs) LPPSP 2T, 4T, 8T 0.15 LPWN38 2T, 4T, 8T 0.11
HOLDING ROD INFORMATION
Part # Fits Size Length Weight (lbs) QL202 2T, 4T, 8T 6" 0.34 QL20212 2T, 4T, 8T 12" 0.45
TAPPED PLATE INFORMATION
Part # Fits Size Weight (lbs) LPPTP 2T, 4T, 8T 0.06
ALP Holding Rods and Tapped Plate are used to mount the Plus Recess Members to the form. Standard finish is plated. Installation Instructions: 1. Insert the tapped plate into the recess member. 2. Insert the lifting pin to the recess member. 3. Align the recess member to a pre-drilled hole in the form. The holding rod is then threaded into the recess using the fixed end coil nut until the thread bottoms out. 4. The movable wing nut is then tightened down until it is snug against the side of the form.
9/16" 3/4" Adjustable Wing Nut 3/8" Coil Thread 3/8" Coil Thread L 1-11/16" Fixed Wing Nut 3/8"Coil Thread 4"
The ALP Lifting Pin Plus Recess Member is constructed of a durable polyurethane material which improves tear, heat, and chemical resistance compared to the standard rubber material. ALP Plus Stud Plate, Wing Nut, Holding Rod, and Tapped Plates are designed so that they are interchangeable for all sizes of recess members.
Stud Plate Tapped Plate Holding Rod Wing Nut Top View Bottom View
Caution: Vibration and placement of the concrete can cause the Magnetic Recess to move. It is recommended that the anchor is secured to the reinforcement before concrete placement.
